Non-magnetic Carbide Rotating Cylinder with HRA92 Hardness 1,500 MPa Flexural Strength and High Durability for Precision Applications

Non-magnetic Carbide Rotating Cylinder with HRA92 Hardness 1,500 MPa Flexural Strength and High Durability for Precision Applications

Λεπτομέρειες:
Τόπος καταγωγής:	zhuzhou, Κίνα
Μάρκα:	Sanxin
Αριθμό μοντέλου:	SX1269
Πληρωμής & Αποστολής Όροι:
Ποσότητα παραγγελίας min:	2
Χρόνος παράδοσης:	5-25 ημέρες
Όροι πληρωμής:	Western Union, t/t, l/c

Επικοινωνήστε

Λεπτομερής ενημέρωση
Περιγραφή προϊόντων

Λεπτομερής ενημέρωση
Επεξεργασία καρβιδίων:	Υψηλή ανθεκτικότητα	Υλικό:	Καρβίδιο βολφραμίου
Υψηλή σκληρότητα:	HRA92	Χημική αντίσταση:	Ανθεκτικό στα περισσότερα οξέα και αλκαλικά
Διάρκεια ζωής:	Μακρύς	Κάμψη:	1500 MPa
Επιφάνεια:	Αμεμπτος	Αιτήσεις:	Εργαλεία κοπής, φθορά εξαρτήματα, εργαλεία εξόρυξης, τρυπάνια κ.λπ.
Εύπλαστο:	Καλή ολκιμότητα και μηχανική ικανότητα	Χαρακτηριστικό:	βελτιωμένη αντοχή
Υπηρεσία:	Ένα βήμα εξατομικευμένη υπηρεσία
Επισημαίνω:	HRA92 Hardness Non-magnetic Carbide Rotating Cylinder , 1 , 500 MPa Flexural Strength WC-Ni Series Carbide Cylinder

Περιγραφή προϊόντων

Magnetic Permeability <1.002 WC-Ni Series Non-magnetic Special Research Carbide Rotating Cylinder

The rotating column is precisely manufactured using WC-Ni non-magnetic cemented carbide. By replacing the traditional cobalt element with a nickel-based binder phase, this scientific solution completely eliminates magnetic interference problems found in ordinary cemented carbide. In magnetic field-sensitive environments such as MRI medical equipment, semiconductor manufacturing, and scientific research instruments, it achieves high precision, no magnetic interference, and exceptional stability.

Main Grades of Non-Magnetic Tungsten Carbide

Grade/System	Main Components	Hardness (HRA)	Flexural Strength (MPa)	Characteristics and Applications
M10 Non-Magnetic Tungsten Carbide	WC-Ni System	92.5	3240	General-purpose non-magnetic molds, corrosion-resistant tools
WC-Ni System	WC-0.75Al-14.25Ni	87.4	1670	Non-strongly magnetic at room temperature, relatively high magnetic permeability
WC-Cr₃C₂-Ni System	WC-Cr₃C₂-Ni	-	-	Commonly used in industry, with 1-3% Cr₃C₂ addition
WC-Cr₃C₂-Mo-Ni System	WC-Cr₃C₂-Mo-Ni	-	-	Adds Mo to improve magnetic properties
MAST-N20	WC-Ni (Japan)	91.0	3300	Highly corrosion-resistant, suitable for nozzles, seals, and molding dies

Grade Selection Tips: The above grades primarily achieve non-magnetic properties by using nickel (Ni) as a binder phase. Different grades have different composition and performance emphases. When selecting, please consider your specific magnetic permeability requirements, hardness, strength, and corrosion resistance.

Core Technologies

Non-magnetic Material Design: A nickel-based binder phase ensures non-magnetic properties from the source. Strict composition control prevents the introduction of magnetic impurities.
Precision Manufacturing and Processing: Specialized grinding technology tailored to non-magnetic materials ensures dimensional accuracy (±0.002mm) and dynamic balance grade (G1.0).
Strict Quality Inspection: 100% magnetic permeability testing ensures every product meets non-magnetic standards. Industrial CT non-destructive testing guarantees internal quality.

Typical Application Scenarios

Medical imaging equipment: Rotating components in MRI scanners prevent interference with magnetic resonance imaging.
Semiconductor manufacturing: High-precision equipment such as wafer transfer robots and photolithography machines prevent magnetic field effects on microelectronic components.
Scientific research equipment: Electron microscopes and high-energy physics experimental equipment ensure measurement accuracy.
Aerospace: Satellite attitude control components and aviation instruments meet non-magnetic environment requirements.
